the engineer in me!

My Projects

1. FPGA-based Equation Solver:

SystemVerilog, C, Python

2. Pager (ESP32 + OLED)

Embedded C, circuit design & power design

  • Works on Morse code
  • Wifi Connected
  • OLED display
  • 4 buttons only!

3. Missile Command in Linux Kernel

x86, Assembly, C, Linux, RTC Interrupt request & Synchronization

  • Text-Video Mode version of arcade game Missile Command.
  • Works on RTC Interrupt.
  • Runs on Linux Kernel in VM.

4. Tiled Matrix Multiplication in CUDA

C, NVIDIA CUDA, Parallel Programming

#include
#define wbCheck(stmt)                                                     \
  do {                                                                    \
    cudaError_t err = stmt;                                               \
    if (err != cudaSuccess) {                                             \
      wbLog(ERROR, "Failed to run stmt ", #stmt);                         \
      wbLog(ERROR, "Got CUDA error ...  ", cudaGetErrorString(err));      \
      return -1;                                                          \
    }                                                                     \
  } while (0)

// Compute C = A * B
__global__ void matrixMultiply(float *A, float *B, float *C, int numARows,
                               int numAColumns, int numBRows,
                               int numBColumns, int numCRows,
                               int numCColumns) {
  //@@ Insert code to implement matrix multiplication here
  __shared__ float subTileA[8][8];
  __shared__ float subTileB[8][8];

  int blockX = blockIdx.x;
  int blockY = blockIdx.y;
  int threadX = threadIdx.x;
  int threadY = threadIdx.y;

  int curRow = blockY * 8 + threadY;
  int curCol = blockX * 8 + threadX;
  float mySum = 0;

  for(int i = 0; i < ceil((float) numAColumns / 8); i++) {

    if(curRow < numARows && (i * 8 + threadX) < numAColumns) {
      subTileA[threadY][threadX] = A[(curRow * numAColumns) + (i * 8) + threadX];
    } else {
      subTileA[threadY][threadX] = 0;
    }

    if(curCol < numBColumns && (i * 8 + threadY) < numBRows) {
      subTileB[threadY][threadX] = B[curCol + (numBColumns * (i * 8 + threadY))];
    } else {
      subTileB[threadY][threadX] = 0;
    }

    __syncthreads();

    for(int j = 0; j < 8; j++) {
      mySum += subTileA[threadY][j] * subTileB[j][threadX]; // 2
    }
    __syncthreads();
  }

  if(curRow < numCRows && curCol < numCColumns) {
    C[curRow * numCColumns + curCol] = mySum;
  }
}

int main(int argc, char **argv) {
  wbArg_t args;
  float *hostA; // The A matrix
  float *hostB; // The B matrix
  float *hostC; // The output C matrix
  float *deviceA;
  float *deviceB;
  float *deviceC;
  int numARows;    // number of rows in the matrix A
  int numAColumns; // number of columns in the matrix A
  int numBRows;    // number of rows in the matrix B
  int numBColumns; // number of columns in the matrix B
  int numCRows;    // number of rows in the matrix C (you have to set this)
  int numCColumns; // number of columns in the matrix C (you have to set
                   // this)

  args = wbArg_read(argc, argv);

  wbTime_start(Generic, "Importing data and creating memory on host");
  hostA = (float *)wbImport(wbArg_getInputFile(args, 0), &numARows,
                            &numAColumns);
  hostB = (float *)wbImport(wbArg_getInputFile(args, 1), &numBRows,
                            &numBColumns);
  //@@ Set numCRows and numCColumns
  numCRows = numARows;
  numCColumns = numBColumns;
  //@@ Allocate the hostC matrix
  wbTime_stop(Generic, "Importing data and creating memory on host");
  hostC = (float*) malloc(numCColumns * numCRows * sizeof(float));

  wbLog(TRACE, "The dimensions of A are ", numARows, " x ", numAColumns);
  wbLog(TRACE, "The dimensions of B are ", numBRows, " x ", numBColumns);

  wbTime_start(GPU, "Allocating GPU memory.");
  //@@ Allocate GPU memory here
  int sizeA = numARows * numAColumns * sizeof(float);
  int sizeB = numBRows * numBColumns * sizeof(float);
  int sizeC = numCRows * numCColumns * sizeof(float);
  cudaMalloc((void **) &deviceA, sizeA);
  cudaMalloc((void **) &deviceB, sizeB);
  cudaMalloc((void **) &deviceC, sizeC);

  wbTime_stop(GPU, "Allocating GPU memory.");

  wbTime_start(GPU, "Copying input memory to the GPU.");
  //@@ Copy memory to the GPU here
  cudaMemcpy(deviceA, hostA, sizeA, cudaMemcpyHostToDevice);
  cudaMemcpy(deviceB, hostB, sizeB, cudaMemcpyHostToDevice);

  wbTime_stop(GPU, "Copying input memory to the GPU.");

  //@@ Initialize the grid and block dimensions here
  dim3 DimGrid(ceil(numCColumns/8.0), ceil(numCRows/8.0), 1);
  dim3 DimBlock(8, 8, 1);

  wbTime_start(Compute, "Performing CUDA computation");
  //@@ Launch the GPU Kernel here
  matrixMultiply<<>>(deviceA, deviceB, deviceC, numARows, numAColumns, numBRows, numBColumns, numCRows, numCColumns);

  cudaDeviceSynchronize();
  wbTime_stop(Compute, "Performing CUDA computation");

  wbTime_start(Copy, "Copying output memory to the CPU");
  //@@ Copy the GPU memory back to the CPU here
  cudaMemcpy(hostC, deviceC, sizeC, cudaMemcpyDeviceToHost);

  wbTime_stop(Copy, "Copying output memory to the CPU");

  wbTime_start(GPU, "Freeing GPU Memory");
  //@@ Free the GPU memory here
  cudaFree(deviceC);
  cudaFree(deviceB);
  cudaFree(deviceA);

  wbTime_stop(GPU, "Freeing GPU Memory");

  wbSolution(args, hostC, numCRows, numCColumns);

  free(hostA);
  free(hostB);
  free(hostC);

  return 0;
}

4. Custom VPS set-up for testing

Linux, Git, Networking

  • Installed Linux Ubuntu 18.04 Bionic Beaver
  • Using Apache
  • Running Node.js
  • Testing for Flutter Web
